2022 - 2024 Ram Cummins 2500 3500 4500 | HP Tuners

Unlock more from your 2022-2024 RAM 6.7L Cummins with custom HP Tuners calibration built to improve horsepower, torque, drivability, and overall performance.

Available for RAM 2500 through 5500 applications, this tuning supports multiple power levels ranging from optimized stock through 200HP, with CSP5 switch-on-the-fly tuning available for compatible pickup models. Optional 68RFE transmission tuning can further improve converter lockup, shift strategy, line pressure, and torque management.

These applications require the RAM CM2450B ECM upgrade service, along with compatible HP Tuners hardware and licensing.

_____________________________________________

Fits

• RAM 2500 3500 4500 5500 – 6.7L Cummins
• 2022 / 2023 / 2024

_____________________________________________

ECM / TCM Unlock Information

ECM:

• Requires the HP Tuners RAM CM2450B ECM Service to upgrade the ECM for tuning.
• The original ECM must be shipped to HP Tuners to complete the unlock/upgrade service.
• ECM licensing requires 6 Universal Credits.

TCM:

• No TCM upgrade or unlock service is required.
• TCM tuning requires separate HP Tuners licensing.
• TCM licensing requires 4 Universal Credits.
• Custom transmission tuning is available only for vehicles equipped with the 68RFE transmission.

_____________________________________________

The Benefits of Tuning

• Increased horsepower
• Increased torque
• Potential improvement in fuel economy
• Improved towing performance
• Customized drivability

Compatible Transmissions

• 68RFE – Commonly found in automatic RAM 2500 pickups
• Aisin – Commonly found in RAM 3500, 4500, and 5500 pickups, Cab & Chassis, and incomplete trucks

Single HP Tune

A Single HP Tune includes one selected power level. Choose your preferred horsepower level when placing your order.

Available Power Levels

• Optimized Stock
• 30HP – Heavy Tow
• 80HP – Light Tow, 12,000 lbs. and under
• 150HP
• 180HP
• 200HP

_____________________________________________

Switchable Tuning (available power levels listed above)

CSP5 Switchable Tuning allows you to select between multiple predetermined power levels without stopping to reflash the ECM.

CSP5 is available only for pickup trucks and is not compatible with Cab & Chassis trucks.

How to Change Power Levels

CSP5 tuning allows you to change maps while the truck is running or driving.

Power levels can be changed using:

• The factory OEM cruise-control buttons, or
• An HP Tuners CSP4/CSP5 pass-through switch

The CSP4/CSP5 pass-through switch plugs directly into the OBD-II port and allows you to change power levels by rotating the switch to the desired position.

The switch also includes an OBD-II pass-through port, allowing another compatible device, such as a monitor, to remain connected at the same time.

There is no need to stop the truck and wait for the ECM to be reflashed when changing between loaded switchable tuning maps.

_____________________________________________

Transmission Tuning

**Transmission tuning is available only for the 68RFE transmission.

Benefits of Transmission Tuning

• Earlier converter lockup
• Increased line pressure
• Revised shift strategy to reduce sluggish shifting
• Earlier downshifts with less throttle input
• Revised torque management

Custom transmission tuning can improve shift behavior, towing performance, and how the transmission responds to increased engine power.

How to Identify Your Transmission

• 68RFE: The transmission pan has a rounded, turtle-shell appearance. The transmission dipstick is located on the passenger side of the engine bay.
• Aisin: The transmission pan is relatively flat and typically has Aisin marked on the side. The transmission dipstick is located on the driver side of the engine bay.

_____________________________________________

Requirements

IMPORTANT:

• A Windows-based computer is required to read and flash tuning into the vehicle and/or transmission.
• Requires a compatible HP Tuners MPVI3 or RTD device.
• RTD4 devices are supported through HP Tuners TDN.
• Requires the 2018+ Dodge Smart Access Cable to enable reading, writing, and special functions.
• Requires the RAM CM2450B ECM Service for ECM tuning.
• The original ECM must be shipped to HP Tuners for the ECM upgrade/unlock service.
• ECM tuning requires 6 Universal Credits.
• TCM tuning requires 4 Universal Credits.
• No additional TCM upgrade service is required.
• Requires VCM Suite BETA 5.3.755 or newer.
• CSP5 tuning is available for pickup trucks only and is not compatible with Cab & Chassis applications.

_____________________________________________

How Does This Work?

1. Order your device, tuning package, ECM service, licensing, and required parts.
2. Complete the Tune Order Form with your truck specifications and modifications.
3. Ship your original ECM to HP Tuners for the required CM2450B ECM upgrade service.
4. We ship your device within 48 business hours after receiving the required vehicle information.
5. Connect your device and send us the required stock readout. Instructions are provided.
6. Our calibrators write your custom tune files.
7. Your files are sent within 24–48 business hours after we receive all required information and files.
8. Follow the provided instructions to flash your truck and complete installation.

Our technicians are available for phone and technical support if assistance is needed during installation.

_____________________________________________

What You'll Need

For a 2022–2024 RAM 6.7L Cummins full kit, you’ll need:

• Device: HP Tuners MPVI3 or compatible RTD device
• Smart Access Cable: 2018+ Dodge Smart Access Cable
• ECM Service: HP Tuners RAM CM2450B ECM Service
• Licensing: 6 Universal Credits for ECM tuning, 4 Universal Credits if adding 68RFE transmission tuning
• Tune Package
• EGR Solution
• DPF / Exhaust Solution

The device is used to read and flash your custom tune files into the truck, while the required hardware and services address the applicable factory systems.

Tunes are typically completed within 24–48 business hours after purchase and once we have received the required Tune Order Form, stock readout files, and vehicle information.

Devices typically ship within 48 business hours after we have received all required vehicle information and order details.

Instructions are provided based on your specific package.

Software Downloads & Instructions

Please ensure you understand and comply with all applicable laws and regulations in your local jurisdiction before purchasing or installing this product.

_____________________________________________

Why Use Torque Works Diesel?

✅ In-house custom calibrations tailored to your truck and intended use
✅ Data-log support and revisions for drivability, reliability, and performance
✅ Financing available to make upgrades more manageable
✅ After-purchase support
✅ Detailed installation and flashing instructions
✅ Technical support included

At Torque Works Diesel, our tunes are custom written in-house.

You’re not receiving a generic third-party calibration used on every truck.

Built, tested, and refined in-house.
