2019 - 2021 Ram Cummins 2500 3500 4500 5500 | HP Tuners

Get more out of your 2019-2021 RAM 6.7L Cummins with custom HP Tuners calibration designed to improve horsepower, torque, drivability, and overall performance.

Available for RAM 2500 through 5500 pickups and cab chassis applications, tuning can be configured with a single power level or CSP5 switchable tuning with five selectable power levels from 30HP through 200HP. Compatible 68RFE-equipped trucks can also be paired with transmission tuning to improve converter lockup, shift strategy, line pressure, and torque management.

______________________________________________

Fits

• RAM 2500 3500 4500 5500 – 6.7L Cummins
• 2019 / 2020 / 2021
• Compatible with Pickups, Cab & Chassis, and Incomplete Trucks

Compatible Transmissions

• 68RFE Automatic – Commonly found in automatic RAM 2500 pickups
• Aisin Automatic – Commonly found in RAM 3500, 4500, and 5500 pickups, Cab & Chassis, and incomplete trucks

_____________________________________________

ECM / TCM Unlock Information

ECM:

• 2018+ trucks require an additional cable to unlock the ECM for tuning.
• The required cable must be used as part of the ECM unlock process before tuning can be flashed.

TCM:

• Custom transmission tuning is available only for vehicles equipped with the 68RFE transmission.
• Transmission tuning requires the appropriate HP Tuners licensing.
• Transmission tuning is not available for the Aisin transmission with this package.

_____________________________________________

The Benefits of Tuning

• Increased horsepower
• Increased torque
• Potential improvement in fuel economy
• Improved towing performance
• Customized drivability

Single HP Tune

A Single HP Tune includes one selected power level. Choose your preferred horsepower level when placing your order.

Available Power Levels

• Optimized Stock
• 30HP – Heavy Tow
• 80HP – Light Tow, 12,000 lbs. and under
• 150HP
• 180HP
• 200HP

Aftermarket Modifications

For this platform, we are currently only accepting custom tuning modifications for an aftermarket turbo.

_____________________________________________

Switchable Tuning

CSP5 Switchable Tuning allows you to select between five predetermined power levels without stopping to reflash the truck.

CSP5 Power Levels

• 30HP – Heavy Tow
• 80HP – Light Tow, 12,000 lbs. and under
• 150HP
• 180HP
• 200HP

How to Change Power Levels

HP Tuners CSP5 tuning allows you to change between the five available power levels while the truck is running.

Power levels can be changed using:

• Compatible steering wheel controls, or
• A physical Cummins CSP4/CSP5 OBD-II Pass-Through Switch

The physical pass-through switch plugs into the vehicle's OBD-II port and allows you to select the desired tune level without reflashing the ECM.

_____________________________________________

Transmission Tuning

Transmission tuning is available only for the 68RFE transmission.

Benefits of Transmission Tuning

• Earlier converter lockup
• Increased line pressure
• Revised shift strategy to reduce sluggish shifting
• Earlier downshifts with less throttle input
• Revised torque management

Custom transmission tuning can improve shift behavior, towing performance, and how the transmission responds to increased engine power.

How to Identify Your Transmission

• 68RFE: The transmission pan has a rounded, turtle-shell appearance. The transmission dipstick is located on the passenger side of the engine bay.
• Aisin: The transmission pan is relatively flat and typically has Aisin marked on the side. The transmission dipstick is located on the driver side of the engine bay.

_____________________________________________

Requirements

IMPORTANT:

• 2018+ trucks require an additional cable for the ECM unlock process.
• All vehicle and transmission tuning requires an HP Tuners MPVI Device + appropriate licensing, unless you already own a compatible HP Tuners MPVI Device and the required licensing.
• A Windows-based computer is required to read and flash tuning into the vehicle and/or transmission.
• Custom 68RFE transmission tuning requires the appropriate additional HP Tuners licensing.
• For this platform, we are currently only accepting aftermarket tuning modifications for an aftermarket turbo.

_____________________________________________

How Does This Work?

1. Order your device, tuning package, licensing, unlock cable, and required parts.
2. Complete the Tune Order Form with your truck specifications and modifications.
3. We ship your device within 48 business hours after receiving all required vehicle information.
4. Complete the required ECM unlock process using the additional cable.
5. Connect your HP Tuners device and send us the required stock readout. Instructions are provided.
6. Our calibrators write your custom tune files.
7. Your files are sent within 24–48 business hours after we receive all required information.
8. Follow the provided instructions to flash your truck and complete installation.

Our technicians are available for phone and technical support if assistance is needed during installation.

_____________________________________________

What You'll Need

For a 2019–2021 RAM 6.7L Cummins full kit, you’ll need:

• Device: Compatible HP Tuners MPVI Device
• HP Tuners Licensing
• ECM Unlock Cable
• Tune Package
• EGR Solution
• DPF / Exhaust Solution

The device is used to read and flash your custom tune files into the truck, while the required hardware addresses the applicable factory systems.

After purchase, tunes are typically completed within 24–48 business hours once we have received your Tune Order Form, required stock readout files, and all necessary vehicle information.

Devices typically ship within 48 business hours after we have received all required vehicle information, the completed Tune Order Form, and any required files.

Instructions are provided based on your specific package.

Software Downloads & Instructions

Please ensure you understand and comply with all applicable laws and regulations in your local jurisdiction before purchasing or installing this product.

_____________________________________________

Why Use Torque Works Diesel?

✅ In-house custom calibrations tailored to your truck and intended use
✅ Data-log support and revisions for drivability, reliability, and performance
✅ Financing available to make upgrades more manageable
✅ After-purchase support
✅ Detailed installation and flashing instructions
✅ Technical support included

At Torque Works Diesel, our tunes are custom written in-house.

You’re not receiving a generic third-party calibration used on every truck.

Built, tested, and refined in-house.

_____________________________________________

Financing

Financing options are available to make your upgrades easier.

Click Here for our Financing Page

_____________________________________________

See Our Customers

Check out trucks tuned by Torque Works Diesel:

Tuned by TWD Customer Page

_____________________________________________

Questions?

FAQs

Email Us: Support@TorqueWorksDiesel.com
